3-6. Completion of Mounting and Adjustment

• Secure the cable with the supplied cable clamp and pan-head screw (M4
• Before using the scale to perform measurements, allow the scale to set for about three hours after mount-
ing so that the secured parts can stabilize and the ambient temperature around the scale can stabilize.
BL57-RE
Cable clamp
Scale
Fig. 3-19
×
8).
Pan-head screw
×
(M4 8)
3-13
(E)
