• Residual risks can be minimised if the "Safety infor-
mation" and the "Proper use" are observed along
with the whole of the operating instructions.
• Do not load the machine unnecessarily: excessive
pressure when sawing will quickly damage the saw
blade, which results in reduced output of the ma-
chine in the processing and in cut precision.
• When cutting plastic material, please always use
clamps: the parts which should be cut must always
be fixed between the clamps.
• Avoid accidental starting of the machine: the oper-
ating button may not be pressed when inserting the
plug in an outlet.
• Use the tool that is recommended in this manual.
In doing so, your machine provides optimal perfor-
mance.
• Hands may never enter the processing zone when
the machine is in operation.
• Release the handle button and switch off the ma-
chine prior to any operations.
6. Technical data
AC motor
Power S1
Operating mode
Idle speed n
0
Carbide saw blade
Number of teeth
Maximum saw blade tooth
width
Swivel range
Mitre cut
Saw width at 90°
Saw width at 45°
Saw width at 2 x 45° (dou-
ble mitre cut)
Protection class
Weight
Laser class
Wavelength of laser
Laser output
220 - 240 V~ 50 Hz
1200 Watt
S6 25%* 1500W
5000 rpm
ø 210 x ø 30 x 2.6 mm
24
3 mm
-45° / 0°/ +45°
0° - 45° to the left
120 x 60 mm
80 x 60 mm
80 x 35 mm
II /
ca. 7.6 kg
2
650 nm
< 1 mW
www.scheppach.com
* S6, continuous operation periodic duty.
Identical duty cycles with a period at load followed by a
period at no load. Running time 10 minutes; duty cycle
is 25% of the running time.
The work piece must have a minimum height of 3
mm and a minimum width of 10 mm.
Make sure that the workpiece is always secured
with the clamping device.
Noise
Total noise values determined in accordance with EN
62841.
Sound pressure level L
pA
Uncertainty K
pA
Sound power level L
WA
Uncertainty K
WA
Wear hearing protection.
The effects of noise can cause a loss of hearing
The above-mentioned noise emission values were
measured in accordance with a standardised test pro-
cedure and can be used to compare one power tool
with another.
The above-mentioned noise emission values can also
be used for the preliminary assessment of exposure.
Warning:
• The noise emissions during the actual use of the
power tool may differ from the above-mentioned
values depending on the power tool being used, in
particular on the type of workpiece being processed.
• Try to keep emissions as low as possible, for ex-
ample by limiting your working time. In this regard,
all the operational cycle phases must be taken into
consideration (such as the times when the tool is
switched off or running idle).
7. Before starting the equipment
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the pack-
aging and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for transport
damage.
99.6 dB
3 dB
112.6 dB
3 dB
