5 3 Operation of interlinked partition walls (installation instructions)
Connection options:
A free-standing partition wall must only be used with cantilevers on both sides!
The adjustable feet must only be used when interlinked with angle connectors as per below connection rules.
Basic configurations
Connection rules
1. Always use a cantilever with adjustable glides on the outside of the
row of partition walls.
2. For a linear connection of more than 3 partition walls, always use a
cantilever with adjustable glides after every second partition wall or
at every odd position in the row of partition walls.
Symbols:
Partition wall
Connector
Adjustable foot
Cantilever with adjustable glides
5 4

Care/cleaning instructions

Cleaning
Clean the RAUWORKS partition wall when it is dirty as required.
- For frames/cantilevers: use a damp cloth and common household
cleaners.
- For fabric: use a damp cloth or an upholstery foam cleaner.
90° 120° 135°
Connection examples
Assembly instructions:
In order to achieve the same height level of the partition walls, turn the
adjustable glides out by approx. 4 mm on the cantilevers.
Do not use very alkaline or acidic cleaning agents. They can damage
the product!
Maintenance
The product is maintenance-free.
DE
180°
