LIST OF COMPONENTS

3 1

Partition wall

Please check whether all individual parts are available prior to
Note:
commencing the assembly.
Pos. A
Designation Partition wall
Quantity 1x
Dimensions 800 x 1400 / 1600 / 1800 x 55 (W x H x D)
(mm)
Illustration
3 2

Accessories

Organisation rail (set):
Pos S
Designation Organisation rail
Quantity 1x
Dimensions B x 80 x 16
(mm)
Illustration
Accessories:
Pos W
Designation DIN A4 tray landscape
Quantity 1x
Dimensions 395 x 280 x 62
(mm)
Illustration
The partition wall (A) can only be used in conjunction with the
Note:
hardware available as accessories.
T
Cover cap
2x
80 x 20 x 12.5
X
DIN A4 tray portrait
1x
272 x 350 x 62
U
Screw
4x
D5x16
Y
Desk set
1x
388 x 166 x 95
R
T-block
4x
10 x 8 x 7.5
