Illustration 13: Fitting the mounting plate (M) onto the partition wall (A).
Illustration 14: Fitting adjustable feet (L) to the mounting plate (M).
36
4 1 4
C
M
a. Join the clamping plate with the bracket as described on page 8.
b. Screw the brackets onto the bottom frame profile as described on
c. Fitting the mounting plate (M) onto the partition wall (A)
G
Make absolutely sure that the screws are tightened properly (recom-
mended tightening torque: 2.5 Nm ± 0.5 Nm). Failure to observe this
may pose the risk that the mounting plates (with adjustable feet, see
next assembly step) are not sufficiently connected to the partition wall
therefore possibly resulting in the adjustable feet detaching from the
partition wall and posing a risk of injury.
d. Push the adjustable foot (L) onto the mounting plate so that it
M
L
e. The adjustable feet are now fully assembled. Repeat steps a to d for
Fitting adjustable feet for interlinking elements using an
angle connector
page 9.
- Screw the screws (G) through the mounting plate (M) into the
clamping plate (C) and tighten them firmly using a 2.5 mm
hexagon socket wrench (see illustration 13). The recommended
tightening torque with a torque wrench is 2.5 Nm ± 0.5 Nm.
- Repeat the previous step for the assembly of the second
adjustable foot for each partition wall.
snaps in fully (see illustration 14).
Ensure that the adjustable foot is in the correct position. Failure to
observe this may result in the risk that the stability of the screen is
impaired therefore possibly resulting in the partition wall falling
over and posing a risk of injury.
further partition walls you want to connect to each other.
