Illustration 29: Assembly of accessories
DIN A4 tray portrait
Desk set
Illustration 30: Individual illustrations of accessories
DIN A4 tray landscape
4 4

Assembly of accessories

Mount the filing tray into the desired groove level of the organisation
rail.
It is necessary to press down both ends of the filing tray in order for it
to lock into place! This ensures that the filing tray holds firmly in place
even under maximum, permissible loads.
Maximum load-bearing capacity of accessories:
The DIN A4 trays landscape and portrait can each bear loads of up to
approx. 4 kg and the desk set can bear loads of up to approx. 3 kg.
Each partition wall side of a single partition wall on castors can bear
a maximum of 6 kg. The maximum load-bearing capacity of each
partition wall side when partition walls are linked is 3 kg.
Please check that accessories fit correctly into the organisation rail.
If they do not fit correctly or are overloaded, accessories including
their content may fall down.
Information regarding the removal of cover caps when the position
is changed:
a. The cover caps must be removed to subsequently change the
position of the organisation rail.
In order to achieve this, carefully remove the cover caps by
tapping them with a small plastic or wooden block and a mallet.
The cover caps and their powder coating may be damaged during
removal with hard objects (e.g. with a screwdriver).
