ROTOCLEAR C PRO
Dimensions Ø40 × 74 (100 incl. connector) mm
Nominal voltage 48 VDC (via data cable)
Test voltage < 15 VDC (detection camera head)
Housing stainless steel
Storage temperature -20 ... +60 °C permissible
Operating temperature +10 ... +40 °C permissible
Protection class IP67 (with data cable connected)
Operation connected to Control Unit
Mounting 2 × external thread for M18 × 1,0
Weight approx. 0.2 kg
Cable length max. 20 m: without signal amplifier
up to 40 m: 1 signal amplifier (2 × data cable with max. 20 m)
up to 60 m: 2 signal amplifiers (3 × data cable with max. 20 m)
Mount
Torque joint flex arm mount 5.0 Nm
Protective hose
Dimensions 1.5 m, individual length; Ø27 mm
Hose Steel, thermal polyelastomer (TPE)
Fitting Stainless steel, M33 × 1.5
Bending radius 90 mm (fixed)
Sheet metal wall thickness 1-3.2 mm
Sheet metal wall cut-out Ø33.5 (+0.5/-0.3) mm
