ROTOCLEAR C PRO

Technical data

Control unit
Nominal voltage 24 VDC, Reverse polarity protection
Power draw 96 W (max., with 2 camera heads and 4 signal amplifiers)
Current 4 A (max., with 2 camera heads and 4 signal amplifiers)
Dimensions 205 × 50 × 109 (125 incl. Clip) mm
Housing Aluminum coated
Protection class IP30
Storage temperature –20 — +60 °C permitted
Operating temperature +10 — +40 °C permitted
FPGA temperature 0 — +85 °C normal operation,
short-term max. 125 °C permissible
Mounting Clip for top hat rail DIN EN 60715
Weight approx. 0,7 kg
Ethernet 2 × 1 Gbit/s
USB 4 × USB 3.0, each 900 mA max.
DisplayPort 1 ×
HDMI 1 ×
Data 2 × M12 x-coded (female)
Output voltage 48 VDC (camera head supply)
Detection voltage 5 VDC (camera head detection)
Torque connector data cable 0.6 Nm
Camera head
Nominal voltage 48 VDC (via data cable)
Dimensions Ø70 × 50 mm (without mounting)
92 OPERATING MANUAL
Housing
Protection class
Nominal speed
Storage temperature
Operating temperature
FPGA temperature
Sealing air connection
Air consumption
Pressure (absolute)
Air purity
Operation
Data
Weight
Mounting
Torque for mounting
Torque rotor screw
Torque connector data cable
Digital zoom
Illumination
Color temperature
Ra (color rendering)
V6.0 (delivery version)
Lens type
Quantity depending on configura-
tion
Aperture
Focal length
Stainless steel, aluminum, glass
IP67 (with sealing air, spinning window and connected data
cable)
4,000 rpm
–20 — +60 °C permitted
+10 — +40 °C permitted
0 — +85 °C normal operation,
short-term max. 125 °C permissible
Ø6 mm
< 25 l / min with specified pressure setting
min. 1,150 mbar
max. 1,500 mbar
ISO 8573-1:2010[3:4:3] (required air purity)
connected to Control Unit
1 × M12 x-coded (female)
alternatively for wet areas: 1 × M12 x-coded (male, via pigtail)
approx. 0.6 kg
2 × thread for M4 screws, thread depth 4.0 mm
1.5 Nm
0.6 Nm
0.6 Nm
4 ×, movable section
1,100 lm, switchable, dimmable (from V5.0)
5,000 K
80
Telemetric
1 × with TFT, F1+TFT, F2+TFT
not available with F1, F2, F1+F2
f 4.0
15,8 mm
93
