The rotor is a wear part. If the window is dirty or
damaged due to chips or other parts, this does
not constitute grounds for a claim.
If the spinning window disk is impacted by a part
that has been flung off, the rotor will need to be
replaced immediately.
Never operate the camera head without a rotor
installed. If the machine is to be operated in the
interim, the camera head is to be securely pro-
tected against penetration and damage by chips,
particles, oils, cooling lubricants and/or other
media, and completely shut down. The provided
covering cap can be used for this purpose. Oth-
erwise, Rotoclear C Pro may be damaged and
become unusable. This will result in a loss of the
warranty.
88
Decommissioning and
disposal
The WEEE Directive prohibits disposing elec-
tronic and electrical equipment in household
waste. This product and its components must
either be recycled or disposed of separately.
Users agrees to dispose of the product in accor-
dance with applicable statutory regulations.
OPERATING MANUAL

Troubleshooting

No image is visible / The user inter-
face cannot be reached.
Check whether all supply lines are correctly con-
nected and the system is supplied with power.
For a connection via HDMI, or DisplayPort check
whether the monitor is correctly connected and
switched on, and if the correct input source is
selected.
When connecting via Ethernet, check in the net-
work connection overview whether the device is
correctly connected. If a DHCP server is available
in the network, it may take a short time to initialize
the IP address. If there is no DHCP server in the
network, you can access the user interface via the
preset static IP address.
Ensure that your company network does not
have any access restrictions that could prevent a
connection. In the case of doubt regarding this,
please contact your network administrator.
The rotor is not spinning
Check whether the device is correctly connected
and switched on. Check whether the rotor can turn
freely and is not blocked. The RPM of the motor is
shown in the menu under "System". If the motor
does not start up when the system is launched,
please contact customer service.
The LED light is not working
Check in the menu whether the light is switched
on. If only one of the two modules or none of them
89
is working, please contact customer service.
The window fogs up / liquid enters
the intervening area between the
rotor and the cover.
Check whether the sealing air is correctly con-
nected and configured and whether there is an
error message from the system. If the settings
are correct, check the cleanliness of the sealing
air according to the requirements indicated in the
chapter "Technical data" in the appendix. If it is too
dirty, install a service unit to ensure the required
purity of the sealing air.
The image is fuzzy or unclear.
Check whether the inside/outside of the rotor
is dirty and clean it with a damp cloth. If neces-
sary, use a suitable cleaning agent such as glass
cleaner or isopropyl alcohol. Also measure the
working distance of the camera head and check
whether it corresponds to the focus position
of the lens. If the camera head is operated at an
incorrect distance, no clear image can be dis-
played. The focus position can only be changed
by the manufacturer because it is sealed to keep
out media, particularly if the rotor fails due to dam-
age from broken tool or workpiece parts. Either
change the working distance or procure a camera
head that has the right focus.
The stream has image interferences.
Check whether your data cables are laid such that
there are no interfering signals, e.g. from power
cables. Use only the data cable provided. Do not
extend the data cables, as every interface impacts
quality and reduces the maximum possible data
