ROTOCLEAR C PRO
Visual Backup Settings
FullHD 1.920 × 1.080 (1080p), 30 frames / second
Visual Backup recordings are automatically divided into approx. 15-minute files for easier handling.
Time lapse Settings
FullHD 1.920 × 1.080 (1080p), 1 frame per 2, 4, 8 second
Slow Motion Settings
Slow motion recordings with 480 frames / second and above are recorded as an image section of
FullHD (1,920 × 1,080 (1080p)) with the specified zoom factor.
Zoom factor 1 x (FullHD) 1.920 × 1.080 (1080p), 120 frames / second
Zoom factor 1 × (HD, scaled) 1.280 × 720 (720p),
Zoom factor 2,1 × 896 × 504,
Zoom factor 3 × (VGA) 640 × 360 (360p),
Storage
Internal
Hard drive (recommended) SolidStateDisc (SSD)
256 GB
1 TB
4 TB
External
Network drive Samba / Cifs 3.0 share
USB flash drive, exFAT (recommended); FAT32, NTFS
External hard disk
Please note that the write and read speeds of external storage devices, may limit recording function-
ality.
96
240 frames / second
480 frames / second
600 frames / second
(Visual Backup for approx. 1 day)
(Visual Backup for approx. 1 week)
(Visual Backup for approx. 1 month)
OPERATING MANUAL
Interfaces
User interface Ethernet:
http://<IP>
https://<IP>
(with optional access restriction),
HDMI, DisplayPort
Fixed IP address 192.168.214.221 (Network interface 1)
192.168.222.222 (Network interface 2)
End device must be on the same network.
API
Protocol Web-socket-, http(s) connection
Description rotoclear.com/en/api
Protocol
Data transmission WebRTC, WebSocket MJPEG, WebSocket H264, RTSP
Data formats fMP4 Stream
Network protocols HTTP, HTTPS
Stream http://<IP>/camera.mjpeg
https://<IP>/camera.mjpeg
rtsp://<IP>:1025
Still image http://<IP>/camera.jpeg
https://<IP>/camera.jpeg
Ports 80 (http), configurable
443 (https), configurable
1025 (rtsp), not configurable
Data Cable
Properties resistant to coolants and oils, suitable for cable carrier, IP67
Bend radius 40 mm (fixed)
80 mm (freely movable)
120 mm (permanently flexible)
97
