Introduction

Safety information
Before installing and operating the equip-
ment, carefully read the user manuals for
Rotoclear C Pro, and the machine tool with its
safety functions. These contain information about
the design and safe use of the camera system.
The manufacturer is not liable for problems
caused by failure to comply with this user manual.
Pay particular attention to note symbols.
Liability disclaimer
The manufacturer is not liable for losses such as
fire, earthquake, third party interference, or other
accidents, nor for losses related to intentional or
unintentional misuse, improper use, or use under
non-compliant conditions. Rotoclear GmbH will
bill any resulting damage.
The manufacturer is not liable for any losses
caused by use or failure to use this product, such
as loss of business income.
The manufacturer is not liable for consequences
related to improper use.
Important information
This product is designed exclusively for the use
of one or two camera heads in combination with a
control unit. Any other use is at your own risk.
Rotoclear, Rotoclear C Pro and "Insights in Sight"
are registered trademarks of Rotoclear GmbH in
58
Germany and other countries.
The type plate is an integral element of the
equipment. Any modification of the equipment
and/or modification of the type plate or opening
the housings voids the conformity and warranty.
Intended use
The intended use of the Rotoclear C Pro includes
applications in machine tools and similar envi-
ronments, where media such as cooling lubri-
cants, oils, water, rinsing and cleaning fluids are
employed.
When a camera is used in such an environment,
the view is obscured or covered due to the exist-
ing media spraying onto the lens or protective
window. That is why Rotoclear C Pro is equipped
with a spinning window in order to ensure a clear
view through the window. Particles or liquids that
land on it are continuously flung off.
This requires that the camera head is in contin-
uous operation, the sealing air is present and
the rotor rotates constantly for the self-clean-
ing effect while the machine is switched on. The
stream of cooling lubricant must not be aimed
directly or targeted at the spinning window of the
camera head.
Quick setup
Fixed IP address 192.168.214.221;
192.168.222.222
User interface Web: http://<IP-address>,
HDMI, DisplayPort
RTSP-Stream rtsp://<IP>:1025
OPERATING MANUAL
Improper use
Avoid misuse of the Rotoclear C Pro by using it
only in the intended environments.
Fasten all components so that they are secured
against falling down. Use the flex arm mount (mag-
netic mounting) only temporarily to determine the
installation position.
Avoid collisions with elements in the vicinity of
the camera head, especially when moving the
machine axes or performing work that requires
entering the machine interior.
Do not install sealing rings in the chamfers of the
rotor outer ring of the camera head rotor. This is
part of the sealing labyrinth and must be able to
rotate freely after assembly.
Liquids such as cooling lubricants or oils must not
run directly onto the sealing labyrinth when the
camera system is switched off.
To mount the camera head on the flex arm mount,
the plug-in connection for the sealing air must be
removed. The sealing air is applied to the system
at the cable gland.
The product is not suitable for operation in poten-
tially explosive atmospheres.
Read the operating instructions before commis-
sioning and using the system.
Data protection notice
Depending on how Rotoclear C Pro is config-
ured and integrated into a company network, vari-
ous protocols can be used to access the camera
head's stream by means of IP addresses. This
59
means that it may be possible to view the record-
ing area. This may mean that staff or service pro-
viders could be observed, i.e. during maintenance
work.
Depending on the laws of the country in which
Rotoclear C Pro is being operated, this may touch
on aspects related to data protection.
Before putting Rotoclear C Pro into opera-
tion, please verify whether any corresponding
measures related to data protection need to be
taken.
Optimizations by the manufacturer
The product is subject to a continuous optimiza-
tion process. At the manufacturer's discretion,
changes can be made to geometry, connections
and interfaces that do not change the basic con-
cept of the product. The manufacturer is not
obliged to actively inform about non-functional
adjustments to the product.
