ROTOCLEAR C PRO

Scope of supply

The camera head can either be preset to one or
two fixed focus positions or equipped with focus-
able optics or a combination of both. Focus posi-
tions are available for the close range or the spin-
dle with a focus range of 200-500 mm (F1), as well
as for the distance range of 500-6,000 mm (F2).
A focusable telemetric tap-focus optic (TFT) is
also available.
The Rotoclear C Pro product is supplied in a
shock-protected, environmentally friendly pack-
aging.
Upon receipt of the delivery, check that the con-
tents are complete and undamaged. The delivery
contains different parts depending on the type of
mounting and equipment.
Only store the product in its original packag-
ing in a dry place and protected from the weather.
Only use the original packaging for return
transportation and dismantle the rotor to protect
it during transportation.
Pay attention to the chapter "Troubleshooting".
62
Camera head
• Camera head 1 ×
Option: F1; F2; F1+F2;
TFT; F1+TFT; F2+TFT
• Plug connector for sealing air 1 ×
• Covering cap 1 ×
• Suction cup 1 ×
Control unit
• Control unit C Pro 1 ×
Option: 256 GB; 1 TB; 4 TB
• Top-hat rail clip 1 ×
• PCB plug connector 1 ×

Required components

• Data cable 1-2 ×
Option: 10 m; 20 m
• Sealing air tube 1-2 ×
• Power cable 1 ×
• Operating Manual 1 ×
OPERATING MANUAL

Accessories

Flex arm mount
(pre-wall mounting)
• Mount 1 ×
• Cable gland 1 ×
• Sealing ring 1 ×
• Screw M4 2 ×
• Usit ring M4 2 ×
• Screw M5 2 ×
• Usit ring M5 4 ×
• Spanner size 27-30 1 ×
• Spanner size 35-38 1 ×
Flex arm mount
(magnetic mounting)
• Mount 1 ×
• Cable gland 1 ×
• Magnetic shoe 1 ×
• Sealing ring 1 ×
• Screw M4 2 ×
• Usit ring M4 2 ×
• Screw M5 2 ×
• Usit ring M5 4 ×
• Spanner size 27-30 1 ×
• Spanner size 35-38 1 ×
Flex arm mount
(through-wall mounting)
• Mount 1 ×
• Cable gland 1 ×
• Sealing ring 1 ×
• Screw M4 2 ×
• Usit ring M4 2 ×
• Spanner size 27-30 1 ×
• Spanner size 35-38 1 ×
63
Ball mount
• Mount 1 ×
• Clamping ring 1 ×
• Ball 1 ×
• Screw M4 2 ×
• Counterpart Mount 1 ×
• Sealing ring 1 ×
• Screw M5 6 ×
• Usit ring M5 6 ×
• Tool for clamping ring 1 ×
Rotoclear C-Extender
• Signal amplifier 1 ×
Mount (Rotoclear C-Extender)
• Mount 1 ×
• Screw M6 2 ×
• Screw M4 2 ×
