ROTOCLEAR C PRO
Plug connection M12 x-coded (2 × male),
in combination with pigtail cable:
M12 x-coded (1 × male, 1 × female)
Torque connector data cable 0.6 Nm
Standard 10 m, Ø7,1 ± 0,4 mm
20 m, Ø7,6 ± 0,4 mm
Classification
up to 15 m Cat 6a
up to 20 m Cat 7
up to 40 m Cat 7, with 1 Signal amplifier
up to 60 m Cat 7, with 2 Signal amplifiers
Length and data cable classification as recommendation in case of in-house procurement. Interfaces
and interference signals can reduce this length.
Latency
HDMI monitor 0.05 seconds
Ethernet direct 0.26 seconds
Ethernet via router 0.24 seconds
RTSP connection Like Ethernet, plus buffering time. Recommended 30–60 ms
Depending on the hardware used and the type of integration. Each additional network component
increases the latency by the respective processing time of the signal. "Real time" defined as < 0.3 s.
System requirements
Web interface PC with Ethernet or mobile device
HDMI surface Monitor with HDMI and touch functionality or mouse
RTSP Stream RTSP compatible software (e.g.: VLC Player)
98 OPERATING MANUAL
Browser
supported
not supported
This information refers to the current version of the browser.
Integration in machine control
DMG MORI
HEIDENHAIN
Further OEMs
Signal amplifier
Data
Torque connector data cable
Firefox Quantum
Google Chrome
Microsoft Edge (Chromium)
Opera
Safari
Microsoft Edge
Microsoft Internet Explorer
CELOS ab Version 6
TNC 640 (from 34059x-08)
TNC 640 with Extended Workspace
Compact (from 34059x-09) **
TNC 620 (from 81760x-05)
iTNC 530 (from 60642x-04 SP17)
TNC 320 (from 771851-05)
TNC 128 (from 771841-06)
CNC PILOT 640 (from 68894x-05)
MANUALplus 620 (from 548431-05)
NC-Software contains Mozilla Firefox V52.5.0 (system require-
ment)
** 21.5" / 24" Monitor (resolution 1,920 × 1,080 pixels)
not yet specified
1 × M12 x-coded (female) for camera head
1 × M12 x-coded (female) for control unit
0,6 Nm
