7. Place the belt (29) on the desired drive belt pulley (30)
and on the parallel running band wheel pulley (31) (S1
or S2).
Ensure that the notches interlock and that the belt (29)
is centred on the drive belt pulley (30) and the band
wheel pulley (31).
8. Press the motor (16) slightly backwards and tighten
the belt tensioning screw (29a) on the motor (16)
again to tension the belt (29).
Use a 6 mm Allen key (E).
9. Fit the band saw blade (6) as described under 12.2.1.
* = may not be included in the scope of delivery!
13 Transport
• The product may only be lifted and transported on the
frame or the foot. Never lift by the guards, adjustment
handles or saw table for transport.
• To transport the product, disconnect the it from the
power supply and set it up in the new position you
want to use it in.
• The band saw blade guard must be in the lower posi-
tion during transport of the band saw.
• The product must be secured against tipping and slip-
ping during transport in vehicles in order to prevent
damage and injuries.
• Never use guards for lifting or transport.
14 Storage
Store the product and its accessories in a dark, dry and
frost-free place that is inaccessible to children.
The optimum storage temperature is between 5°C and
30˚C.
Store the product in its original packaging.
Cover the product to protect it from dust or moisture.
Store the operating manual with the product.
15 Electrical connection
The electrical motor installed is connected and ready
for operation. The connection complies with the ap-
plicable VDE and DIN provisions. The customer's
mains connection as well as the extension cable used
must also comply with these regulations.
15.1 Important information
In the event of overloading, the motor will switch itself off.
After a cool-down period (time varies) the motor can be
switched back on again.
15.2 Damaged electrical connection
cables
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
• Pressure points, where connection cables are passed
through windows or doors,
• Kinks where the connection cable has been improper-
ly fastened or routed,
• Places where the connection cables have been cut
due to being driven over,
40 | GB
• Insulation damage due to being ripped out of the wall
socket,
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not be
used and are life-threatening due to the insulation damage.
Check the electrical connection cables for damage regu-
larly. Ensure that the connection cables are disconnected
from electrical power when checking for damage.
Electrical connection cables must comply with the appli-
cable VDE and DIN provisions. Only use connection ca-
bles with the same designation "H05VV-F".
The printing of the type designation on the connection ca-
ble is mandatory.
Safety information for replacing damaged or defective
mains connection cables
Connection type Y
If it is necessary to replace the mains connection cable,
this must be done by the manufacturer or their represen-
tative to avoid safety hazards.
15.3 AC motor
Connections and repair work on the electrical equipment
may only be carried out by electricians.
• The mains voltage must be 220 V - 240V~.
• Extension cables up to 25 m long must have a cross-
section of 1.5 mm².
Please provide the following information in the event
of any enquiries:
• Type of current for the motor
• Motor data - type plate
16 Repair & ordering spare parts
After repairs or maintenance, make sure that all safety-re-
lated parts are installed and are in perfect condition. All
parts which may cause injury must be kept where they
are inaccessible to children or others.
ATTENTION
According to the German Product Liability Act, no liabili-
ty is accepted for damage caused by improper repairs
or by not using original spare parts.
Such work should be performed by a customer service
centre or an authorised specialists. The same applies to
accessory parts.
Connections and repairs
Connections and repair work on the electrical equipment
may only be carried out by electricians.
16.1 Ordering spare parts
Please provide the following information when ordering
spare parts:
• Model designation
• Item number
• Type plate data
Spare parts / accessories
Band saw blade - Article no.:
Table inlay - Article no.:
www.scheppach.com
7901505702
5901514013
