® HMI Case – Sealing Ring
27.2 M2Smart
Pos. Item no. Description
10 pcs. sealing rings for the handle
03 80512867
27.3 Wall Bracket for M2Smart
Pos. Item no. Description
Wall Bracket for M2Smart
04 49400210
Passive wall bracket for secure mounting of the M2Smart
on the wall and easy stowage of the cable.
The mounting bracket must be mounted with suitable mounting
material. The mounting material is not included in the scope of
delivery.
Passive wall bracket for the M2Smart
Figure 32: Passive wall bracket for the M2Smart
Dimensions of the wall bracket for M2Smart
®
