To lock the M2Smart HMI Case, close the eccentric lever:
Figure 30: Locking the M2Smart
22 Components of the M2Smart
22.1 Emergency Stop
22.1.1 Technical Data of the Emergency Stop
Contact type
Electrical life
Mechanical life
B10d
Rated operational
voltage
Rated operating
current
Forced opening
Unlocking
Standards
Table 19: Technical data for Emergency Stop
The Emergency Stop is always mounted on the right side of the M2Smart
on the left side.
®
M2Smart HMI Case_Bedien- Projektierhandbuch_Operating Project Engineering Manual_V1.06_de_en
®
HMI Case
®
2-channel Emergency Stop button; 2 n/c
50,000 switching cycles
50,000 switching cycles
250,000
35 V DC
2.0 A
According to EN 60947-5-1, Appendix K
Right and left rotation
EN 60947-5-1, EN 60947-5-5, EN ISO 13850
HMI Case
Technical data
®
HMI Case. It cannot be mounted
