21.2.4 Closing and Locking HMI Cases
®
The M2Smart HMI Case is now closed again.
®
Figure 29: Closing the M2Smart HMI Case
®
When closing the M2Smart HMI Case, make sure that no cables are pinched.
®
Place the M2Smart HMI Case on a table or flat surface to change the tablet.
®
Be careful not to get your fingers caught in the slide mechanism when closing the M2Smart HMI Case.
Risk of injury.
Make sure that there are no objects in the guides of the sliding unit.
®
