TEUFELBERGER multiTOOL Gebrauchsanleitung Seite 6

use
of the OP 8mm e2e. Make sure that the lengths
of the two rope ends of the Airliner 9,1mm e2e
are approximately the same.
OD Loop 7mm T:
Pic. 4
Pic. 6
Note that the ropes must not cross but always lie
parallel.
NOTE: The parts OP 8mm e2e and OD Loop 7mm
T are certified as individual PPE and may be used
as follows:
– This anchor device was tested to EN 795, Class B,
for use by a single person using personal protective
equipment.
– Pursuant to EN 795, this anchor device (anchor
point) for personal protection equipment must be
capable of withstanding a force of 18 kN in every
described mode of use when new.
– This assembly is intended for use in a work
6
Pic. 5
Pic. 7
position-ing system. It shall not be used for fall
arrest applica-tions. Under no circumstances shall
the potential fall distance exceed 500mm.
– Whenever possible, the anchor point should
be vertically above the user. The potential for, and
con-sequences of pendulum swings shall be man-
aged at all times.
– Check the structure to which you fasten the
anchor device as to whether or not it is of suitable
and suf-ficient strength for the purposes of sup-
porting any foreseeable loading in cluding that in an
emergency contingency. Prior to using it have the
anchor device checked by a competent person. The
product can be used as a belay for the rescuer after
a single fall – this must only be done if a suitable
structural anchor (tree / branch) is chosen. (After
all, in the type examination, dynamic loading was
tested twice without making any readjustments of
or other cor-rections to the anchor device.) The
structural anchor (tree / branch) must withstand
more than 12 kN.
– Always attune the length of the anchor de-
vice to the object it is looped around.
OD Loop 7mm T:
When using the product in a single or double
loop configuration, the length of the rope that is
actually utilized for the looparound must be at
least three times as long as the circumference of
the object it is to be looped around so that the
rope is oriented in the pulling direction. When
using the product as choke sling, be sure that
the provided thimble, if any, is not exposed to
bending loads.
– A work positioning system must always be
main-tained as taut as possible from the anchor
point to the belayed person (avoid rope slack).
MODES OF USE - OP 8mm e2e
This anchor device can be used in double strand
configuration:
