GB
General technical approval/
General design certification
No. Z-40.21-589 of 19 November 2021
Rotational-moulded container combination made
from polyethylene (PE) Type: CUBE Tank 980 l
1.3
Container
(1) The tests described in Table 3 must be carried out on the containers, in compliance with
the measured values detailed in the Tables.
Table 3: Tests and test specification
Property
Surfaces
Wall thicknesses,
container masses,
Leakproofness
Table 4: Minimum wall thickness/container mass
Property
Wall thickness
in mm
Minimum
mass in kg
(2) The test pressure must be set at 1.3x the static pressure of the liquid to be stored, but at
least that of water, relative to the bottom of the container.
1.4
Hinged lid
The polyethylene hinged lids described in Annex 2, Section 2 must be included in the factory
production control. The requirements of Annex 2, Section 2 apply.
6
Data sheet DVS 2206-1:2011-09 Non-destructive tests on tanks, apparatus and piping made of thermoplastics –
Z105800.21
52
Test specification
Based on
DVS 2206-1
6
see Table 4 of this Annex
See Section 1.3(2) of
this annex
Measuring
point/stipulation
Tank base
Top of tank
Side walls
Container without fixtures
Dimensional checking and visual inspection
Annex 4
Page 2 of 2
Documentation
Frequency
Record
every container
Value
Inner container
Collection container
8.0
4.1
5.6
57.0
3.0
-
2.3
19.5
1.40.21-59/20
