Structure
3.2 Metering pump - 'EcoAdd'
9
17
16
15
14
13
Fig. 2: Layout of 'EcoAdd'
1 Cable bushing for mains cable/power supply
2-5 Cable bushings to the main board with terminals
6 Level monitoring (suction lance connection)
7 Control unit
8 ON/OFF button
9 USB port
10 Touchscreen
10240750 Ver. 5-12.2023
7
8
10
11
12
1 2 3 4 5 6
11
12 Position of type plate
13 Cable bushing for mains cable/power supply
14 Suction connection / suction valve
15 Pump head
16 Vent screw
17 Pressure connection / pressure valve
14
Display cover
