9.2 Shutting the engine off
Allow the power generator to run for a short time (approx.
30 seconds) without load before switching it off so that it
can "cool down". To do so, switch off the connected con-
sumers.
1. Set the on/off switch (13) to the "OFF" position.
2. Disconnect the power consumers from the product.
3. Set the ventilation on the tank cover (2) to "OFF".
9.3 Operating display (6) (Fig. 3)
The operating display is active when the engine is run-
ning.
9.4 Overload indicator (7) (Fig. 3)
The overload protection becomes active if the power con-
sumption is too high and switches off the 230 V ~- sock-
ets (9).
1. Switch off the product, as described in section 9.2.
2. Disconnect the power consumers from the product.
9.5 Oil warning indicator (8) (Fig. 3)
The indicator activates when the oil level is too low and
deactivates as soon as the oil level is sufficient.
If the oil level is too low, the oil warning indicator (8) lights
up during the start attempt. Top up engine oil, as de-
scribed under 8.2 and repeat the starting procedure.
9.6 Automatic oil cut-off
The automatic oil cut-off system responds when there is
too little engine oil. The oil warning indicator (8) starts
flashing when there is too little oil in the engine. The indi-
cator lamp starts to light up when the oil quantity has not
reached the safety quantity. The engine switches itself off
after a short time. It is not possible to start the engine until
the engine oil has been filled (see chapter 8.2.
9.7 Energy saving switch (10) (Fig. 3)
To reduce the fuel consumption when idle, move the en-
ergy saving switch (10) to the "ON" position.
The energy saving switch (10) must be switched off when
electrical products that require a high starting current are
connected, for example a compressor. Even when the
power generator is started, the energy saving switch must
be initially set to "OFF".
9.8 USB connection (11) (Fig. 3)
This power generator is equipped with two USB connec-
tions. These can be used to charge smartphones for ex-
ample.
10 Cleaning
• Switch the engine off before carrying out any cleaning
or maintenance work.
ATTENTION
Danger of burning!
Wait until the product has cooled down before perform-
ing cleaning or maintenance work.
26 | GB
ATTENTION
Take any contaminated maintenance material and oper-
ating materials to a collection point designated for this
purpose.
10.1 Cleaning
• Keep protective devices, air vents and the motor
housing as free of dust and dirt as possible. Rub the
product clean with a clean cloth or blow it off with
compressed air at low pressure. We recommend that
you clean the product directly after every use.
• Clean the product at regular intervals using a damp
cloth and a little soft soap. Do not use any cleaning
products or solvents; they could attack the plastic
parts of the product. Make sure that no water can pen-
etrate the product interior.
11 Maintenance
WARNING
Always wear protective gloves and a mask during main-
tenance work!
11.1 Maintenance plan
Always comply with the following maintenance intervals in
order to ensure problem-free operation. See chapter
Maintenance plan.
ATTENTION
At initial start-up, engine oil and fuel must be filled.
11.2 Check the oil level (Fig. 5+6)
1. Proceed as described under 8.2.
11.3 Oil change
Change the engine oil after 20 operating hours, then after
50 hours or every three months.
The engine oil change should be carried out while the en-
gine is at operating temperature.
1. Place the product on a level, even surface.
2. Remove engine cover (3) as described under 8.2.
3. Provide a collection bucket (not included in the scope
of delivery).
4. Open the oil dipstick (16) and drain warm engine oil
into the collection container by tilting the power gener-
ator.
5. Fill up with new engine oil (approx. 0.35 l).
6. Screw the oil dipstick (16) in again.
7. Dispose of the used oil properly.
