Note: Some electrical devices (motorised jigsaws,
drills, etc.) can have high power consumption if they are
used under difficult conditions. Some electric devices
(e.g. TV devices, computers. etc.) may not be operated
with a generator. In case of doubt, check with the man-
ufacturer of your device.
Overload protection
The power generator is equipped with overload pro-
tection. This deactivates the respective sockets in the
event of an overload.
Attention! If this situation occurs, reduce the electric
power that you are drawing from the power generator
or remove defective devices that are connected.
Attention! Defective overload switches may only be
replaced with identical overload switches with the
same power data. Contact customer service for this.
12V DC connection (14)
The 12V DC connection is switched off in the event on
an overload. The 12V DC connection can be reactivat-
ed by pressing the overload switch (11).
230V~ sockets:
The 230V~ sockets (15) are switch off in the event on
an overload. The 230V~ sockets can be reactivated by
pressing the overload switch (10).
400V 3~ socket:
The 400V 3~ socket (13) is switch off in the event on an
overload. The 400V 3~ socket can be reactivated by
switching the overload switch (10) on.
• The power generator is suitable for 230 V~ and 400
V 3~ AC voltage devices.
• The 12V DC port (12) can be used to load the 12V
battery. Use an adapter cable for this. (not suitable
for car batteries)
• Attention! The power generator is not suitable for
being connected to a house mains as an emergency
power supply. It can cause damage to the generator
or other electrical devices.
Shutting the engine off
• Allow the power generator to run for a short time
without load before switching it off so that the unit
can "cool down".
• Set the on/off switch (7) to the "OFF" position using
the key.
26 | GB
Oil warning indicator (8)
The indicator activates itself when the oil level is low
and switches the engine off. As soon as the oil level is
sufficient, the engine can be restarted.
Winter operation
As the generator is driven by a diesel engine, special
measures must be taken for winter operation. The use
of "winter diesel" is required if operating the diesel gen-
erator in outside temperatures of -3° to -10° Celsius.
The switchover of the diesel fuel to "winter diesel" takes
place mainly at the end of October, differing from coun-
try to country. Ask your filling station about the time to
switchover to "winter diesel".
• If the diesel generator is operated regularly, meas-
ures do not need to be taken as the switchover to
"winter diesel" takes place automatically.
• If the generator is not used for a long time in the au-
tumn, but you want to reuse it in the winter, it is rec-
ommended to keep the tank almost empty. Ask your
filling station about the time to switch over to "winter
diesel" and fill the tank with "winter diesel" before
use in outdoor temperatures from -3° to -10° Celsius.
• If, however, the diesel fuel "congeals", the diesel
generator must be brought into a room with temper-
atures of approx. +10° Celsius for approx. 12 hours.
• If the tank is half full or full with normal diesel, then
it must be emptied.
• The tank must then be filled with "winter diesel".
If almost empty or up to half empty, it is sufficient to fill
up with "winter diesel".

10. Cleaning

We recommend that you clean the device directly after
every use.
Clean the device at regular intervals using a damp
cloth and a little soft soap. Do not use any cleaning
products or solvents; they could attack the plastic parts
of the device. Make sure that no water can penetrate
the device interior.

11. Transport

m WARNING
Before transport or parking indoors, allow the ma-
chine's engine to cool down to avoid burns and risk of
fire. If you want to transport the device, empty the tank
beforehand. Clean coarse dirt from the device using a
brush or a hand brush.
