8Archive, PC and user menu

8.1.0

Archive Menu

The ARCHIVE Menu makes it possible to manage the archive of
keys saved by the user. It is also possible to access the import
and export functions (USB flash drive).
How to access the page:
• From the MAIN Menu, select:
1 2
4
Options displayed:
1. This function makes it possible to access the archive
containing the keys identified during the search and de-
coding processes.
2. This makes it possible to export/import a file stored in a
USB flash memory from/into the database. The export
and import functions allow the customer to exchange
customised data between machines or create backup
copies of the exported archive.
3. This makes it possible to access the CARD MAKER func-
tion, where the user can create or add new key cards or
modify the cards of keys already in the database.
4. Makes it possible to save and manage the texts that shall
be recalled to engrave the key head and the metal tags.
• For further information select "
Copyright by Keyline - Italy
ARCHIVE, PC AND USER MENU
8.1.1

Card Maker Menu

Through this menu it is possible to access a series of functions
that make it possible to create or implement new key cards or to
modify the cards of keys already in the database.
A
3
E
Options displayed:
A. Makes it possible to search the CUSTOM CARDS
created by the user, to modify or use them.
B. Makes it possible to create a CUSTOM CARD
starting from a card saved in the database.
C. Makes it possible to create a CUSTOM CARD
starting from a card created by the user.
D. Makes it possible to create a new card starting
from an available key type.
E. Makes it possible to add a codes table to a card
saved in the database.
F. Makes it possible to add a codes table to a card
created by the user.
• For further information select "
" from the display.
NINJA VORTEX
8.2.0
Through this menu it is possible to access the functions to inter-
face NINJA VORTEX with queuing software that might reside in a
remote PC or USB flash drive.
It is possible to import job queues containing several processes
(JOBS).The JOBS, in turn, contain information for each key to be
cut, such as: type of key, type of bitting, and number of copies to
B C D
be cut.
The programme makes it possible to select and execute only one
JOB at a time, until the queue is exhausted.
F How to access the page:
Options displayed:
" from the display.
Man. cod. B409959FG

Personal Computer Menu

• From the MAIN Menu, select:
2
1
1. These menus manage and process job queues created
with Instacode and Promaster key processing software
and sent to the machine.
2. This menu makes it possible to import, manage and pro-
cess job queues saved in DAT format files.
• For further information select " " from the display.
Keyline S.p.A. 19
