1General Information and Safety instructions

Glossary
1
4
7
6
5
01. Head
02. Neck
03. Shoulder
04. Blade
05. Tip
06. Back
07. Bitting
Dimple keys A "dimple" key is characterised by a series
of conical engravings (or dimples) on the
key blade, with different dimensions and
shapes (flat or inclined).
Laser-Style keys Such keys are called "Laser" on account of
their special bitting style across the profile.
Key sample The "original" key from which, through de-
coding, a duplicate key is obtained.
Key blank A key with no engraving that is cut following
the profile of the key sample.
2 Keyline S.p.A.
GENERAL INFORMATION AND SAFETY
INSTRUCTIONS
The user's and maintenance manual of the "NINJA VORTEX" for the
duplication of laser keys and dimple keys with flat and inclined bit-
ting, contains all operation instructions on the best way to use the
machine while guaranteeing the safety of operators.
1.1.0

Scope and contents of the manual

This manual provides basic information on the installation, operation
and maintenance of the key duplicating machine.
2
Users must follow the instructions contained in this manual scrupu-
lously, especially those concerning safety norms and ordinary main-
3
tenance.
1.1.1

How to store the manual

The manual must always be kept with the machine it refers to.
The manual must be stored in a safe place, away from dust and mois-
ture and it must be accessible to all users who shall consult it any
time they are in doubt on how to operate the machine.
1.2.0

Manufacturer's address

Keyline S.p.A.
Via Camillo Bianchi
31015 Conegliano (TV) - ITALY
Tel.: +39.0438.202511
Fax: +39.0438.202520
Website: www.keyline.it
E-mail: info@keyline.it
To facilitate communication please state:
- the name of the customer;
- the identification data shown on the machine plate.
1.3.0

Working conditions

1.3.1

Intended use

The key cutting machine described in this manual has been designed
for the electronic duplication of dimple keys with flat and inclined bit-
ting.
NINJA VORTEX
Warning: Important!
It is not possible to decode painted keys or keys made
of non-conductive materials.
1.3.2

Improper Use

The improper use of the machine includes using the tool to perform an
operation that it was not intended for. Should this occur the manufac-
turer shall take no responsibility for damage to materials or persons
and shall consider all warranties on the machine void.
1.4.0

Safety legislation

The key duplicating machine was designed and produced in com-
pliance with the harmonised standards from time to time in force
and complies with the Essential Health and Safety Requirements
of Annex I to the Machinery Directive 2006/42/EC.
Moreover, key duplicating machines produced by Keyline S.p.A.
satisfy the requirements of the Low Voltage Directive 2014/35/
EU and Electromagnetic Compatibility Directive 2014/30/EU.
Warning: Important!
Users must be informed about the instructions con-
tained in the following screens.
Users must carefully follow the instructions contained
in this manual.
1.4.1

General safety requirements

Warning: Important!
Make sure that the grounding system is well
connected.
Always unplug the machine (turn off the main switch)
before servicing mobile parts that are electrically
operated.
Do not pour water or other liquids onto electrical cables
and connections.
