7. Technical data

AC motor
Nominal power S1
Operating mode
Idle speed n
0
Drill chuck clamping range
Max. drill stroke
Size of base plate
Distance of drill-chuck to base
plate
Weight approx.
Protection class
Laser class
Laser wavelength
Laser power
Technical changes reserved!
* After an uninterrupted operating period of 5 minutes, the device should
be allowed to rest until its temperature has dropped to within 2 K (2° C)
of room temperature.
The workpiece must have a minimum height of 3 mm and a mi-
nimum width of 45 mm. Make sure that the workpiece is always
secured with the clamping device.
Noise
Sound and vibration values were measured in accordance with
EN 62841.
48 | GB
www.scheppach.com
220 - 240 V~ 50 Hz
710 Watt
S2 5min* 900W
500 - 2600 min
1,5 - 13 mm
70 mm
320 x 305 mm
280 mm
8,3 kg
II /
650 nm
< 1 mW
-1
2
