9.3 Assembling the chuck guard (fig. 2)
1. Insert the chuck guard (13) into the holes provided in the machine
frame.
2. Secure the chuck guard (13) by hand-tightening the screws (C).
9.4 Assembling the handle (fig. 2)
1. Remove the pre-mounted fastening screw (B).
2. Slide the spacer sleeve (K) and the handle (8) onto the mount (D), as
shown in Fig. 2.
3. Tighten the blade fastening screw (B) firmly.
9.5 Assembling the clamping lever for depth stop (fig. 2)
Assemble the clamping lever for depth stop (6) as shown in fig. 2.
9.6 Fastening to a work surface (fig. 3)
Fasten the device to the work surface by bolting the base plate (1) to the
work surface.

10. Operation

10.1 Operation of the display (fig. 4)
• Switching the display on/off:
Press the button (I, 2-3 sec.) until the display (9) switches on or off.
• Adjusting the oscillation rate
• Press the
button to increase the oscillation rate (fig. 12.1).
• Press the
button to decrease the oscillation rate (fig. 12.2).
• Switching the laser cross on/off:
The laser cross can be switched on or off by pressing the button (12.3).
10.2 Height adjustment (fig. 1)
The position of the machine head can be adjusted to suit the workpiece
height or the workpiece length.
1. Hold the handle (8) firmly.
2. Release the clamping lever for the height adjustment (5).
3. Set the position of the machine head with the handle (8).
www.scheppach.com
GB | 51
