6. Immediately remove used batteries from the de-
vice and dispose of them properly! Do not dis-
pose batteries with household waste. Defective
or used batteries must be recycled according to
Directive 2006/66 / EC. Give back batteries and
/ or the device has been offered to the collective
facilities. About disposal facilities you can inform
by your municipal or city government.
7. Do not allow batteries to heat up!
8. Do not weld or solder directly on batteries!
9. Do not dismantle batteries!
10. Do not allow batteries to deform!
11. Do not throw batteries into fire!
12. Keep batteries out of the reach of children.
13. Do not allow children to replace batteries without
supervision!
14. Do not keep batteries near fire, ovens or other
sources of heat. Do not use batteries in direct
sunlight or store them in vehicles in hot weather.
15. Keep unused batteries in the original packaging
and keep them away from metal objects. Do not
mix unpacked batteries or toss them together!
This can lead to a short-circuit of the battery and
thus damage, burns or even the risk of fire.
16. Remove batteries from the equipment when it
will not be used for an extended period of time,
unless it is for emergencies!
17. NEVER handle batteries that have leaked with-
out appropriate protection. If the leaked fluid
comes into contact with your skin, the skin in this
area should be rinsed off under running water
immediately. Always prevent the fluid from com-
ing into contact with the eyes and mouth. In the
event of contact, please seek immediate medical
attention.
18. Clean the battery contacts and corresponding
contacts in the device prior to inserting the bat-
teries.
Residual risks
The machine has been built according to the state
of the art and the recognised technical safety re-
quirements. However, individual residual risks
can arise during operation.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the "Safety infor-
mation" and the "Proper use" are observed along
with the whole of the operating instructions.
• Do not load the machine unnecessarily: excessive
pressure when sawing will quickly damage the saw
blade, which results in reduced output of the ma-
chine in the processing and in cut precision.
30 | GB
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
• When cutting plastic material, please always use
clamps: the parts which should be cut must always
be fixed between the clamps.
• Avoid accidental starting of the machine: the oper-
ating button may not be pressed when inserting the
plug in an outlet.
• Use the tool that is recommended in this manual.
In doing so, your machine provides optimal perfor-
mance.
• Hands may never enter the processing zone when
the machine is in operation.
• Release the handle button and switch off the ma-
chine prior to any operations.

6. Technical data

AC motor ..................................... 220 - 240 V ~ 50 Hz
Power S1 .................................................... 1200 Watt
Operating mode ................................ S6 25%* 1500W
Idle speed n ...............................................5000 min
0
Carbide saw blade ...................ø 210 x ø 30 x 2,6 mm
Number of teeth .......................................................48
Maximum saw blade tooth width ........................3 mm
Swivel range ......................................... -45° / 0°/ +45°
Mitre cut ..........................................0° - 45° to the left
Saw width at 90° .....................................120 x 60 mm
Saw width at 45° .......................................80 x 60 mm
Saw width at 2 x 45°
(double mitre cut)......................................80 x 35 mm
Protection class .................................................. II /
Weight ......................................................... ca. 7,6 kg
Laser class ................................................................2
Wavelength of laser .........................................650 nm
Laser output.................................................... < 1 mW
* S6, continuous operation periodic duty.
Identical duty cycles with a period at load followed by
a period at no load. Running time 10 minutes; duty
cycle is 25% of the running time.
The work piece must have a minimum height of 3
mm and a minimum width of 10 mm.
Make sure that the workpiece is always secured
with the clamping device.
Noise
Total noise values determined in accordance with EN
62841.
Sound pressure level L ........................99,6 dB(A)
pA
Uncertainty K ..................................................3 dB
pA
Sound power level L .......................... 112,6 dB(A)
WA
Uncertainty K ..................................................3 dB
WA
Wear hearing protection.
The effects of noise can cause a loss of hearing
-1
