12.4 On / Off switch control unit
13. Chuck guard
14. Chuck
15. Wing screws for parallel stop
16. Parallel stop
17. Quick-clamp screw
18. Pointer
19. Retaining screw
20. Scale
21. Inspection door

3. Scope of delivery

• 1 Drilling machine
• 1 Quick clamp (2)
• 1 Base plate (1)
• 1 Parallel stop (16)
• 1 Handle (8)
• 1 Spacer sleeve (K)
• 1 Chuck guard (13)
• 2 Screws 3,0 x 12 (C)
• 1 Clamping lever (6)
• 1 Allen key, 4 mm (L)
• 1 Chuck key (G)
• 1 Operating manual
• 1 Assembly material (N)
• 1 Nut (J)
• 1 Allen screw (B)

4. Proper use

The bench drill is designed for drilling in metal, wood, plastic and tiles.
Chuck clamping range: 1.5 - 13 mm.
The device is intended to be used by do-it-yourselfers.
