Configuration and special functions

You can make individual configuration settings in the menu.
To do this, proceed as follows:
• Press and hold down the "Menu" button for four seconds.
• Use the handwheel to select the menu item (see below).
• Press the OK button to go to the sub-menu.
• The changes can be saved as soon as you finish working
through a particular menu item. "OK" appears on the display
to enable this.
• You can use the "Menu" button to switch back to the menu
item one level up in each case. You can also use it to cancel
the setting process and exit the configuration menu.
• The menu is automatically exited after 90 seconds if no
buttons have been pressed during this time.
Display
content Explanation
PRG Temperature configuration for automatic mode
DAT Date and time setting
Display of valve position, battery status and
VST
reception status
Display of window position, battery status and
WST
reception status
KON HomeMatic device configuration
DEC Time setting for routine descaling function
C/F Temperature unit setting (Celsius or Fahrenheit)
Setting defining whether the actual value or
A/S
setpoint is to be displayed
T/H Alternating temperature and humidity display
LIG Duration of display backlighting
OFF Valve offset setting
Position that the valve actuator automatically
EPO
approaches in the event of an error
WOT Open-window temperature
RES Reset to the initial state
48
Page
49
37
52
52
39
53
54
54
54
55
46
53
44
49
