Content/ Description/ Amount
7
Chuck protection
8
Vice
9
Fastening screws
Remove the protective oily coating on the machine table.
Use this traditional household grease or stain.
Warning:
To prevent fire and carbon monoxide poisoning, never use
gasoline, petroleum or similar flammable materials.
Protect the table, the column and the surface equipment
through a protective wax coating from rusting. Wipe all
parts thoroughly with a clean, dry cloth.
Equipment
1
Base plate
2
Pillar
3
Drilling table
4
Machine head
5
Laser
6
Toothed rack
7
Keyless drill chuck
8
Grips
9
Drill chuck protection
10 Depth stop
11 Motor
12 On-Off switch
13 Belt protective hood
14 Vice
ASSEMBLY INSTRUCTIONS
WARNING:
For your own safety never connect plug to power source
outlet until all assembly steps are completed and you
have read and understood the safety and operational in-
structions
Column to base, Fig. 2
1 Position base {A) on floor or bench.
2 Place column assembly {B) on base and align holes
in column support with holes in base.
3 To attach and fasten the pillar unit, screw the three
(or 4) screws (a) into the base plate and tighten them
with a wrench.
Fig. 1
dp 16 sl
1
1
4
21
