Feed handles to the shaft hub.
Screw the feed handles (A) tightly into the threaded holes
in the hub (B).
Installing the chuck, Fig. 7
1 Clean the conical hole in the chuck (A) and the spindle
cone with a clean piece of fabric. Make sure there
are no foreign particles sticking to the surfaces. The
slightest piece of dirt on any of these surfaces will
prevent the chuck from seating properly. This will
cause the drill bit to wobble". If tapered hole in the
chuck is extremely dirty, use a cleaning solvent on
the clean cloth.
2 Push the chuck up on the spindle nose as far as it
wiII go.
3 Turn chuck sleeve anticlockwise (when viewed from
above) and open jaws in chuck completely.
4 Legen Sie ein Stück Holz auf den Maschinentisch
und senken Sie die Spindel bis auf das Holzstück ab.
Drücken Sie fest, damit das Futter genau sitzt.
Fastening radial drill press to supporting surface
For your own safety, it is highly recommended to install
the machine on a bench or similar.
ADJUSTMENTS
WARNING:
All the necessary adjustments for the good working of
your drill press have been done at the factory .Please do
not modify them.
However, because of a normal wear and tear of your tool,
some readjustments might be necessary .
WARNING:
Always unplug our tool from power source before any ad-
justment"
25
