Tip: Safety switch
If you want to adjust speed you have to open the pulley
cover. The device switches off immediately to avoid the
risk of injuries.
Removing the chuck.
Open jaws of chuck as wide as they go by turning chuck
sleeve (A) anticlockwise (when viewed from above).
Carefully tap chuck with mallet (B) in one hand while
holding chuck in other hand to prevent dropping it when
released from spindle nose.
Depth stop, Fig 10.1
The depth stop enables the drilling of holes in the work-
piece until a defined depth. Adjust the ring (6) using the
scale to the desired depth and tighten the ring with the
wing nut (7).
Positioning table and workpiece, Fig. 11
Always place a piece of back up material (A) ('wood, ply-
wooood...) on the table undemeath the workpiece (B).
This wiII prevent splitering or making a heavy burr on
the underside of the workpieces as the drill bit breaks
through. To keep the back up material from spinning out
of control it must contact the left side of the column as
illustrated.
Warning: to prevent the work piece or the backup mate-
rial from being torn from your hand whiile drilling, posi-
tion them to the left side of the column. If the work piece
or the backup material are not long enough to reach the
column, clamp them to the table. Failure to do this could
result in personal injury.
Note: for small pieces (A) that cannot be clamped to the
table, use a drill press vise (Optional accessory).
The vice (B) must be clamp or bolt (C) to the table to
avoid injury from spinning work and vise or tool breakage.
Drilling a hole.
Make a dent in the workpiece where you want the hole,
using a center punch or a sharp nail. Before turning the
31
