General Notes
• When you unpack the device, check all parts for pos-
sible transport damages. In case of complaints the
supplier is to be informed immediately. Complaints
received at a later date will not be acknow ledged.
• Check the delivery for completeness.
• Read the operating instructions to make yourself fa-
miliar with the device prior to using it.
• Only use original parts for accessories as well as for
wearing and spare parts. Spare parts are available from
your specialized dealer.
• Specify our part numbers as well as the type and year
of construction of the device in your orders.
Technical Data
Chuck size mm
Speeds min
Motor
Motor power
Watt
Spindle cone
seat
Drilling chuck
cone seat
Drilling chuck
clamping range
mm
Spindle rise and
fall range mm
Chuck to
worktable mm
Spindle base
working range
mm
Column diam.
mm
Overal height mm
Weight kg
Subject to technical modifications!
Noise parameters acc. to EN 1870-1: 1995-07
The rates indicated are emission values; they are not nec-
essarily safe working values. Although there is a corre-
lation between emission and immission level, it cannot
reliably be derived whether additional precautions are re-
quired or not. The immission level prevailing at the work-
ing place can be influenced by the following conditions:
Duration of noise, characteristic of the work room, other
noise sources like the number of machines, and neigh-
bouring procedures. The reliable work place rates can dif-
fer from one country to the other. This information should
enable the operator, however, to make a reliable evalua-
tion of the danger and risks.
dp 16 sl
16
460 – 2480
550
B16
B16
3–16
60
175
340
59,5
715
28,0
7
