CAREL Modbus® Digitalvariablen (Modbus®:COILS)
75 75 Status relay function
76 76 State relay logic
77 77 Aktivieren der EIN/AUS-Verwaltung vom BMS
78 78 Disable via serial
79 79 Verwaltungsaktivierung durch BMS erforderlich
82 82 Enable preheat probe
CAREL Modbus® Integer-Variablen (Modbus®:REGISTERS)
2 210 Firmware release
4 212 Hardware id
7 215 Humidifier status
13 224 Dipswitch status
27 235 Max production T
28 236 Min production T
32 240 Wash duration
33 241 Delay at start-up
34 242 Hours for maintenance
35 243 Maintenance reminder
36 244 Modulation period
39 247 Max fill T
40 248 Refill T
41 249 Max drain T
42 250 Empty drain time
43 251 Low lev delay
53 261 Operating hour counter
54 262 Unit hour counter
62 270 Serial Secondary Command
63 271 Secondary Value
65 273 Remote board offline time
69 277 Waiting for restart
70 278 Percentage of max prod T for level test
72 280 Drain delay in standby
73 281 Max refill T
74 282 Max HLev Time
87 295 Secondary 1 FW release
89 297 Secondary 1 status
92 300 Secondary 1 hour counter
93 301 Secondary 2 FW release
95 303 Secondary 2 status
98 306 Secondary 2 hour counter
99 307 Secondary 3 FW release
101 309 Secondary 3 status
104 312 Secondary 3 hour counter
105 313 Piezoelectric transducer hour counter
106 314 Countdown to replace piezoelectric transducers
107 315 Life of piezoelectric transducers
108 316 SW Version
109 317 SW Date
110 318 Percentage output
111 319 Type of control
112 320 Max_production
113 321 Min_production
114 322 Type of main probe
115 323 Main probe offset
116 324 Min active main probe
117 325 Max active main probe
118 326 Main probe alarm delay
119 327 Limit probe type
120 328 Limit probe offset
121 329 Min active limit probe
122 330 Max active limit probe
123 331 Limit probe alarm delay
124 332 Time event for wash activation
125 333 Time event for wash activation
126 334 Washing time during operation
127 335 Washing countdown during operation
128 336 Washing time due to inactivity
129 337 Washing countdown due to inactivity
130 338 Total washing time
131 339 Total washing countdown
132 340 Scheduled wash hours
133 341 Scheduled wash minutes
134 342 Scheduled wash weekday
136 344 Request from BMS serial
139 347 Main board offline time
140 348 Preheat probe alarm delay
143 351 Supervisor control type
Typ
R/W
R/W
R/W
R/W
R/W
Tipo
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
