Wall mounting

Safety

Danger due to residual voltage from capacitors.
An electric shock can be fatal!
▶
Risk of burns from the heat sink when open.
This can result in personal injury.
▶
▶
▶
IMPORTANT! The IP 54 protection class only applies if the cover is firmly
screwed to the back.
Selecting wall IMPORTANT! Different fixings may be required to fit the Ohmpilot depending on
plugs and screws the type of surface. Fixings are therefore not included in the scope of supply. The
installer is responsible for selecting the correct fixings. It must be ensured that
the screws are tight and that the wall is stable.
Recommended To install the Ohmpilot, Fronius recommends the use of steel screws with a dia-
screws meter of 4 - 6 mm.
Risk of contamination or water on the terminals or electronics
This may result in damage to the Ohmpilot.
▶
90
WARNING!
Before opening the device, wait for the capacitors to discharge (15 seconds).
WARNING!
Wear suitable protective equipment.
Allow heat sink to cool.
Do not touch the hot heat sink.
CAUTION!
When drilling, ensure that terminals and electronics do not become dirty or
wet.
