Fronius Ohmpilot Bedienungsanleitung Seite 116

Connecting via WPS (WiFi Protected Setup)
1
2
Connecting via access point and manual configuration of the WLAN settings
1
2
3
4
NOTE!
Desired network not listed.
If the desired WLAN network is not listed, end access point mode by pressing
the button again and repeat the process.
5
116
Press the button on the Ohmpilot 1x.
The blue LED flashes (once) as long as WPS is active.
Press the WPS button on the router within 2 minutes.
If the blue LED on the Ohmpilot lights up permanently, the connection to the
network was successful.
The inverter automatically searches for the Ohmpilot, and the search process
can take up to 5 minutes. If the red LED is not lit and the green LED is fla-
shing, the Ohmpilot is working correctly.
Press the button on the Ohmpilot 2x.
The blue LED flashes (twice) as long as the WLAN access point is active (30
minutes). Before the access point is opened, it searches for available WLAN
networks.
Activate the "Ohmpilot" WLAN network on your smart device or PC.
In the browser, enter the address http://192.168.250.181 or http://ohmpi-
lotW.local. Alternatively, the Ohmpilot can also be searched on the network
using the Fronius Solar.web App.
Select the desired network in the WLAN network tab.
Click on "Save & Connect", enter WLAN password.
If the blue LED on the Ohmpilot lights up permanently, the connection to the
network was successful.
The inverter automatically searches for the Ohmpilot, and the search process
can take up to 5 minutes. If the red LED is not lit and the green LED is fla-
shing, the Ohmpilot is working correctly.
