Explanation of
symbols - instal-
lation position
88
Do not install the Ohmpilot in:
- Areas where ammoniac, corrosive vapours, acids or salts are
present (e.g. fertiliser stores, ventilation openings from
cattle sheds, chemical plants, tanneries, etc.)
Do not install the Ohmpilot in:
- Places where there is an increased risk of damage from
farm animals (horses, cattle, sheep, pigs, etc.)
- Stables or adjoining areas
- Storage areas for hay, straw, chaff, animal feed, fertilisers,
etc.
The Ohmpilot is designed to be dustproof. However, in areas
with a heavy build-up of dust, the thermal efficiency may still
be impaired by dust forming on the cooling surfaces. Regular
cleaning is necessary in such situations. We therefore recom-
mend not installing the device in areas and environments with
high dust accumulation.
Do not install the Ohmpilot in:
- Greenhouses
- Storage or processing areas for fruit, vegetables or viticul-
ture products
- Areas used in the preparation of grain, green fodder or ani-
mal feeds
The Ohmpilot is designed to be installed vertically on a vertical
wall.
Do not install the Ohmpilot horizontally.
Do not install the Ohmpilot on a sloping surface.
Do not install the Ohmpilot on a sloping surface with its con-
nection sockets facing upwards.
