5.2 Description of the Keyboard
TOUCH KEYBOARD
The user can configure the device by
simply touching on the touch keyboard.
Depending on the selected setting, the
electronic feedback system automatically
adjusts the correct operating frequency.
POWER (Ref. L front endpaper)
The desired level of power is adjustable
from 7 levels, from 1 to 7, by selecting
the numbers on the touch keyboard in
the "power" column.
IRRIGATION (Ref. M front endpaper)
The delivery rate of the peristaltic pump
is adjustable from 6 levels, by selecting
the numbers on the touch keyboard in
the "irrigation" column:
From 1 to 6= the pump flow goes from 8
ml/min to approximately 65 ml/min.
MODE (Ref. N front endpaper)
Depending on the type of surgery, it is
possible to choose one of the 3 options
available from the "mode" list:
1. Dedicated to the most delicate
surgeries and to the lift of the sinus
membrane;
2. Dedicated to the cut and to the
removal of the mineralized bone;
3. Dedicated to the cut and to the
removal of very thick mineralized
bone.
flex
mode
power power irrigation
7 6 3
6 5
2
5 4
1
4 3
3 2
2 1
pump
1 1
1
flex
power irrigation irrigation mode
7 6 3
6 5
2
5 4
1
4 3 3
3 2 2
2 1 1
pump
1 1
flex
irrigation mode mode
power
3
7 6
6 5 2
5 4 1
4 3
3 2
2 1
pump
1 1
USE
