FILLING THE IRRIGATION TUBING KIT
(Ref. O front endpaper)
The device is equipped with the "pump"
key which allows to perform the PUMP
function.
The PUMP function can be used at the
beginning of the treatment, to fill the
entire irrigation tubing up to the insert,
so that the surgery can be started with
the necessary irrigation (see Chapter 5.5
on page 22).
SYMBOLS (Ref. P front endpaper)
PIEZOSURGERY® flex is equipped with
a diagnostic system able to detect
operating anomalies. Icons are displayed
on the touchpanel according to the
detected operating anomalies.
To
help
the
user
malfunctioning part, four symbols are
foreseen which are described in Chapter
9.1 on page 34.
5.3
Foot Pedal Button
In case the foot pedal is not functioning,
the button on the back of the device, left
hand side, under the symbol
used to bring the treatment to its end.
CAUTION: In the event you need to use
the foot pedal button, first disconnect it from
the socket of the unit.
WARNING: Use the foot pedal button
only upon user request. The users must train
their staff on how and when they have to use
this button.
18
flex
identify
the
, can be
be used only in case of malfunction of the
foot pedal supplied with the unit. This button
allows to end the surgical treatment in the
event of a foot pedal malfunction.
power
irrigation
7
6
6
5
5
4
4
3
3
2
2
1
1
1
power
irrigation
7
6
6
5
5
4
4
3
3
2
2
1
1
1
WARNING: The foot pedal button must
flex
mode
3
2
1
pump
pump
flex
mode
3
2
1
pump
