NOTE: The foot pedal comes equipped
with a bracket that allows it to be
moved to the place most suitable for the
operation, without the need to use your
hands to move it.
The bracket can also be positioned
horizontally if it is not used;
Connect the foot pedal to the back of
the device in the socket marked with
the symbol , by means of the plug of
the pedal cable, until you hear a "click"
sound.
In order to disconnect the foot pedal
from the device grab the connector of
the foot pedal, press the release flap and
pull the connector back;
NOTE: The button on the back of the
device, left hand side, under the symbol
, can be used to bring the treatment
to its end in case the foot pedal is not
functioning.
Fit the drip stand for supporting the
solution bag into the dedicated hole;
3
4
5
INSTALLATIoN
