Bit Beschreibung Erweiterter Alarmstatus 2
18 User Defined Alarm 3 (Software)
19 User Defined Alarm 4 (Software)
20 User Defined Alarm 5 (Software)
21 User Defined Alarm 6 (Software)
22 User Defined Alarm 7 (Software)
23 User Defined Alarm 8 (Software)
24 Skin Sensor Low Temperature (Software)
25 Skin Sensor High Temperature (Software)
26 Skin Sensor Hot Spot (Software)
27 Skin Sensor Leak (Software)
28 –
29 –
30 –
31 –
Bit Beschreibung Servostatus
0 Servo up
1 Servo down
2 Servo Top Limit
3 Servo Bottom Limit
4 Off-Level
5 Water/Interface Mode
6 Testing/Stowing/Calibrating
7 Blocked/Frozen
Bit Beschreibung Servo-Alarmstatus
0 Level Hi Hi Alarm
1 Level Hi Alarm
2 Level Low Alarm
3 Level Low Low Alarm
4 Product Temperature Data Not Valid
5 Product Level Data Not Valid
6 Product Temperature No Response
7 Product Level No Response
8 Servo up
9 Servo down
10 Servo Top Limit
11 Servo Bottom Limit
12 Off-Level
13 Water/Interface Mode
14 Testing/Stowing/Calibrating
15 Blocked/Frozen
Konfiguration von DCC Slave
