MAINTENANCE

10 Maintenance
11

Technical data

11.1

Technical specifications

The "Technical Data" section contains only an extract of the technical data of the sensor.
The complete technical data can be found on the homepage
en
Features
Sensing range
Min. sensing range
Sensing range max.
Recommended sensing range for the best performance 40 mm ... 140 mm
1) Object with 90% remission (based on standard white DIN 5033)
Emitted beam
Light sender
Type of light
Light spot size / distance

Communication interface

Table 14: Communication interface
IO-Link
IO-Link
Data transmission rate
Electrical data
Supply voltage U
B
Ripple
Current consumption
Protection class
1) Limit values
Reverse polarity protected U
Residual ripple max. 5 V
Digital output
Output current I
Circuit protection
Max. response time
28 O P E R A T I N G I N S T R U C T I O N S | W4F MultiPulse
This SICK sensor is maintenance-free.
We do, however, recommend that the following activities are undertaken regularly:
• Clean the optical interfaces using a plastic cleaner, do not use acetone or methy‐
lated spirits.
• Check the fittings and plug connectors
No modifications may be made to devices.
Subject to change without notice. Specified product properties and technical data are
not written guarantees.
connections
B
ss
max.
www.sick.com under the part number of the sensor.
WTB4FP-xxxxx1
4 mm ... 220 mm
1)
WTB4FP-xxxxx1
PinPoint-LED
Sichtbares Rotlicht
4.5 mm / 160 mm (Typ)
WTB4FP-xxxxx1
1.1
COM2
WTB4FP-xxxxx1
DC 10 ... 30 V
1)
≤ 5 Vss
25 mA
III
WTB4FP-xxxxx1
≤ 100 mA
A, B, D
1)
< 0.5 s / < 0.1 s
2)3)
WTB4FP-xxxxx2
4 mm ... 100 mm
30 mm ... 60 mm
WTB4FP-xxxxx2
PinPoint-LED
Sichtbares Rotlicht
2 mm / 50 mm (Typ)
WTB4FP-xxxxx2
1.1
COM2
WTB4FP-xxxxx2
DC 10 ... 30 V
1)
≤ 5 Vss
25 mA
III
WTB4FP-xxxxx2
≤ 100 mA
A, B, D
1)
< 0.5 s / < 0.1 s
2)3)
8027506/2022-02-28 | SICK
Subject to change without notice
