HYDRAULIC ROTATORS
GB

4. GENERAL DESCRIPTION

The FERRARI INTERNATIONAL S.p.A. hydraulic rotator
is designed to be installed on the end of the crane boom
and allows the connection and use of equipment such as
buckets, polyp grabs, forks, and so on.
SHAFT VERSION
FR 15
Models Static load
FR 15
FR 35
FR 50
FR 55
FR 15
22
FR 35
Dinamic load
kg kg
1200 600
3500 1750
5000 2500
5500 2700
FR 35
The rotator is equipped with hydraulic hoses that are
connected following the instructions shown by the
symbols situated on the head and on the shaft.
5. TECHNICAL
CHARACTERISTICS
FR 50
Weight Pressure
kg bar
10 250
17 250
25 250
28 250
According 2006/42/CE EN4413:2012 EN12100:2010
FR 50
FR 55
Rotation Torque
Nm
360° cont. 500
360° cont. 900
360° cont. 1100
360° cont. 1300
FR 55
Oil flow
l/min
10
20
20
20
