Survey And Construction; Technical Data - probst HVZ-ECO Betriebsanleitung

Hydraulische verlegezange für den universellen baggereinsatz
Vorschau ausblenden Andere Handbücher für HVZ-ECO:
Inhaltsverzeichnis

Werbung

Verfügbare Sprachen

Verfügbare Sprachen

General
4.3

Survey and construction

Operating handle
1
2
Rotating head (360°)
Height adjustment of the rollers
3
4
Main clamping (machine side)
Side clamping
5
4.1

Technical data

Main gripping width
Type
HVZ-ECO
580 - 1.260 mm
(22¾ – 49¾")
600 - 1.200
(23½"--55")
*
= Opening width of the Installation Clamp
51400034
Gripping depth
50-160 mm
*
(2"-6¾")
*
**
**
**
=
Adjustment of gripping depth
6
7
Main clamping (facing bedding sand)
Steel lamellas
8
Side gripping width Carrying capacity/working
*
960 - 1,400 mm
*
(37¾ – 57")
**
900 - 1,400
**
(35½"-55")
Gripping range (for stone layer dimensions)
V3
Dead weight
load limit (WLL)
400 kg
(880 lbs)
(approx. 460
13 / 41
ca. 210 kg
lbs)
GB
