Safety Marking

PROHIBITION SIGN
Symbole
WARNING SIGN
Symbole
REGULATORY SIGN
Symbole
OPERATING SIGNS
Symbole
51400034
Meaning
It is not allowed to be under hanging loads. Danger to life!
Caution! Danger of squeezing! Touch only at handles.
Meaning
Danger of squeezing the hands.
Meaning
Read operating instructions before operating.
Meaning
Scale for adjusting the side clamping (ÖW 960-1,400 mm)
Adjustment of the main clamping (gripping range ÖW 570 – 1.470
mm)
Volumetric flow (l/min), usable min. 25, optimal 35 – 40, max. 80
Working pressure (bar), usable min. 180, optimal 200, max. 320
Minimum excavator operating weight: from approx. 2,3 t
Stop lever for locking the side clamping (if only the main
clamping is used).
V3
6 / 41
Order-No Size:
2904.0210 30 mm
2904.0209 50 mm
2904.0204 80 mm
2904.0367 205x30 mm
Order-No Size:
2904.0221 30 mm
2904.0220 50 mm
2904.0107 80 mm
Order-No Size:
2904.0666 Ø 50 mm
2904.0665 Ø 30 mm
Order-No Size:
2904.0595 248x200 mm
2904.0596 280x100 mm
2904.0621 58x36 mm
2904.0643 95x50 mm
