Preparing the UV-Detector 2500 for Operation
Preparing the UV-Detector 2500 for Operation
Unpacking
Standard delivery Smartline UV-Detector 2500
Standard delivery Smartline UV-Detector 2500 fiber optics
After unpacking, please check the device and accessories thoroughly for
any damage that may have occurred during transport. If necessary, put
forward any claim for damages to the carrier.
Use list "Standard delivery" and check if the UV-Detector 2500 delivery is
complete. Please contact our service department if you miss something
or if you need support.
Remove the transport protections from the display and from the flow cell
housing.
1. Smartline UV-Detector 2500 without cell
2. Operation Manual
3. Power Supply Cable
4. RS-232 Cable
(9 pin, female/female)
5. Analog Connection Cable (Cinch/Cinch)
6. Plug Strips with Connectors (WAGO)
7. Hex socket key (4 mm)
1. Smartline UV-Detector 2500 without cell
2. Two fiber optical cables, 750 mm
3. Operation Manual
4. Power Supply Cable
5. RS-232 Cable
(9 pin, female/female)
6. Analog Connection Cable (Cinch/Cinch)
7. Plug Strips with Connectors (WAGO)
8. Hex socket key (4 mm)
