Spare Parts; Technical Data - Knauer Smartlibe UV Detector 2500 Handbuch

36

Spare Parts

Technical Data

A4071 Deuterium lamp
A4072 Halogen lamp
A4073 Halogen lamp with socket (needed for first installation
of a halogen lamp)
M1479 Power supply cable
A0895 RS-232 connection cable (9 pin, female/female)
M0205 WAGO plug strip (8 x)
M0165 WAGO lever latch
G1023 Integrator cable
M1588 Analog connector cable
A1467 10 pin Ribbon Cable
A1131 Repair kit for analytical flow cells
A1132 Repair kit for preparative flow cells
A4124 Test cell (dummy)
A4125 Test cell (dummy) with fiber optical connectors
A4126 Holmiumoxidefilter Test cell
A4128 Holmiumoxidefilter Test cell with fiber optical
connectors
A0740 two fiber optical cables (750 mm)
A0742 one fiber optical cable (750 mm)
A0743 two fiber optical cables (any length up to 5 m)
Wavelengths
Lamps
Edge filter
Wavelengths accuracy
Scan function
Range of measurement
Sensitivity
Noise
Baseline drift
Time constants
Scalable integrator out
Autozero Range
Display
Control
Power Supply
Weight
Dimensions
GLP Support
190 - 740 nm
Deuterium (standard), Halogen (alternatively)
370 nm
+ 2 nm
analog, stop flow mode
0-2 AU
-5
2 x 10 AU at 240 nm and time constant 1.0 s
-5
1 x 10 AU at 240 nm
-5
15 x 10 AU/h at 240 nm
0.1/ 0.2 / 0.5 /1.0 / 2.0 / 5.0 / 10.0 s
+ 1,0 V in 16 steps adjustable
Full Scale
2 x 24 Digits
RS 232 interface, analog output,
remote connector, keypad
90-260 V, 47 - 63Hz, 70 VA
6 kg
226 x 135 x 390 mm (W x H x D)
Detailed trace report with operating hours of
total, lamp, servo motor; number of lamp
ignitions, service information
Technical Data
