Preparing the UV-Detector 2500 for Operation

The front door of Smartline UV-Detector 2500 fiber optics

Fig. 7
The metal front plate
Detector 2500 fiber optics
Fig. 8
5
1
2
3
4
5
Front view of UV-Detector 2500 fiber optics
Front view of UV-Detector 2500 fiber optics
1
2
3
4
Display
keypad
Outlet for fiber optical cables
Auto-Zero-key
Standby-key
of the Smartline UV-
(behind the door)
1
1
2
1 fiber optical connectors
2 Screw for removing the
optical bench
9
