3.2.3 Settings on the module A23 (not double rectifiers)
R617: 0Ω resistance as earth - reference potential M connection
On delivery, M is connected to earth. Remove this resistor only to avoid disturbances from earth
loops, i.e. if the electronic reference potential is otherwise connected to earth (e.g. via the reference
potential connection terminal of the power supply unit. The 0Ω resistor R210 on the A50 module
must additionally be removed when using the additional power suppy A50 (see Chapter 9.1).
S500: Adjust the rated voltage range with S500 (DIP-Fix) (see Chapter 4)
S1: The start-up enabling status can be switched through to the 'Warning' output (terminal X36) with S1
(DIP-Fix). When S1 is open, the 'Warning' relay is opened only in the event of an excess
temperature.
S501: Close switch S501 only for flexible compliance (only allowed with increased pre-chokes)
Works setting and normal operation = open
R9 between soldering terminals A and B can be removed to increase the ramp-up time from 1 to 2
seconds.
3.2.4

Fan (X19)

Terminals
AC 230V ±10%, 50 to 60Hz ±5% mains connection for the fan
X19-1
X19-2 current consumption 0.84A
Table 3.7 Fan
Terminal X19 fused with the fuses (F3 and F4):
T2A/250V time-lag 5x20mm
(19198-T2A/250V Messrs. Wickmann-Werke GmbH respectively 0034.3993 FSD Messrs. Schurter)
or
T2A/250V time-lag 6.3x32mm (¼" x 1¼")
(19343-T2A/250V Messrs. Wickmann-Werke GmbH respectively 0034.5231 FSD Messrs. Schurter)
3.2.5 Temperature sensor (only brought out at terminal X30 with double rectifiers)
The R100 temperature sensor is brought out at terminals for external evaluation.
Operating values for overtemperature disconnection:
Unit order No.
6SE7031 - 7EE85 - 0RA0
6SE7033 - 2EE85 - 0RA0
6SE7036 - 1EE85 - 0RA0
Rated value of R100 = 6800 ohms
Siemens AG 6SE7087-6AE85-0AA0
Common Rectifier Operating instructions
Function description
Operating value of R100 (ohms)
1400
920
750
Connection
perm. conductor
cross-section
2
(mm ) (AWG)
0.2 to 2.5 24 to 14
3-7
ENGLISH
