Connection
Unit order No.
6SE70..
31-7EE85-0AA0
32-7EE85-0AA0
33-8EE85-0AA0
34-6EE85-0AA0
36-1EE85-0AA0
31-4FE85-0AA0
32-4FE85-0AA0
33-5FE85-0AA0
34-2FE85-0AA0
35-4FE85-0AA0
32-2HE85-0AA0
33-5HE85-0AA0
34-2HE85-0AA0
35-4HE85-0AA0
1)
31-7EE85-0RA0
1)
33-2EE85-0RA0
1)
36-1EE85-0RA0
Table 3.3 Recommended mains fuses
Column 1: This fuse with gR characteristic protects the semiconductors. At the same time, they also
have line protection characteristic which can be used if the appropriate conductor cross-
sections are chosen, e.g. in accordance with DIN VDE 0100 Part 430 (to be applied for
preference).
Column 2, 3: Semiconductor protection only, lines are not reliably protected. Line protection is assured only
by correlating the line protection fuses to the installed conductor cross-section in accordance
with the applicable regulations - e.g. DIN VDE 0100 Part 430.
1)
The fuses indicated in column 1 are not allowed to be used when these devices are operated with a 40°
conduction angle (especially in the 18-pulse application).
3-4
ENGLISH
Mains supply cable fuses
Column 1
Siemens gR
(SITOR)
Preferred type
A Type
160 3NE1224-0 250
250 3NE1227-0 400
350 3NE1331-0 500
450 3NE1333-0 630
560 3NE1435-0 800
— 160
— 315
315 3NE1230-0 500
400 3NE1332-0 560
500 3NE1334-0 800
— 315
315 3NE1230-0 500
400 3NE1332-0 560
500 3NE1334-0 800
160 3NE1224-0 250
315 3NE1230-0 450
560 3NE1435-2 800
Column 2
Siemens (SITOR)
A Type A
3NE3227 250
3NE3232-0B 400
3NE3334-0B 550
3NE3336 700
3NE3338-8 900
3NE3224 200
3NE3230-0B 350
3NE3334-0B
3NE3335
3NE3338-8
3NE3230-0B
3NE3334-0B
3NE3335
3NE3338-8
3NE3227 250
3NE3233 550
3NE3338-8 900
Column 3
Bussmann
US-standard
Type
170M3616
170M3619
170M3622
170M4617
170M5615
170M3615
170M3618
—
—
—
—
—
—
—
170M3616
170M3622
170M5615
